What is the exact procedure to train/learn/register new TPMS sensors to the Grenadier?

[parb]

Can I test program a sensor and redo it if I get it wrong?

Does the sensor need to be in a tire to be programmed? I'm thinking I'd like to get the procedure tested once before I have the tires and sensors installed on the rim.

And thanks btw. Super useful!



[anand]

Can I test program a sensor and redo it if I get it wrong?

Does the sensor need to be in a tire to be programmed? I'm thinking I'd like to get the procedure tested once before I have the tires and sensors installed on the rim.

And thanks btw. Super useful!

You can program/reprogram the sensor as many times as you'd like

The sensor doesn't need to be in a tire to be programmed, just mark the sensors so you know which one goes into which position



[parb]

After doing the updates, switching to Euro, and turning off TPS Prog limit...

Quick mode, Ineos, Grenadier, select the dates, scan all sensors. Go around and grab the sensor data. Store this (I just took a pic with my phone).

Then you can go to Program sensor; and if I'm not mistaken, Copy by Activation.

If there is a span of time in between scanning the factory sensors, and programming the MX sensors, just use Copy By Manual Input. This will allow you to go around one at a time and program each of the MX sensors by entering the hex ID of the factory sensor in that location (what you wrote down or took a picture of above)

Just got my programmer. I updated it over wifi without any issues.
Is there a particular reason to switch to euro? I see the ineos in the US database. Any other reason for it?



[TheDocAUS]

Just got my programmer. I updated it over wifi without any issues.
Is there a particular reason to switch to euro? I see the ineos in the US database. Any other reason for it?

Originally the Grenadier was only visible under Europe, sounds like US now also.



[anand]

Just got my programmer. I updated it over wifi without any issues.
Is there a particular reason to switch to euro? I see the ineos in the US database. Any other reason for it?

Originally the Grenadier was only visible under Europe, sounds like US now also.

Originally it was Euro only; now they include it for the US.... A few weeks ago whilst programming my new sensors (my first set of MX sensors inexplicably died after 6 weeks) the TS508 refused to see them or program them unless I switched to Euro (despite trying US Grenadier first), so thus why I suggested it



[parb]

Originally it was Euro only; now they include it for the US.... A few weeks ago whilst programming my new sensors (my first set of MX sensors inexplicably died after 6 weeks) the TS508 refused to see them or program them unless I switched to Euro (despite trying US Grenadier first), so thus why I suggested it

Got it. Thank you!



[G-Tank]

I got the Tire and Wheel package shipped and they installed the Schrader SCHRFK4S TPMS sensors, which off course are NOT registering.

Is there a way to reprogram/clone these sensors with the AUTEL tool ?



[parb]

Hi @anand I just had my tires mounted on the steel rims I bought. It was super easy to clone the sensors following your procedure.
I had to do the spare tire manually by scanning the spare and entering the hex code manually but that was pretty easy too.

Thank for the help!



[Weatherman]

I purchases a TS508WS off of Amazon and updated it over Wifi when I took it out of the box. I tried reprogramming a new set of MX sensors with the TS508WS. I was not able to get it to work. I could successfully read the IDs for the stock sensors and record them, but I was unable to reprogram the new sensors. It seems like Autel removed the ability to set the IDs of their sensors.

It shows support for the Grenadier in the vehicle selection. Under the "Program Sensor" menu it only shows one option: "Auto Create 1-16 Sensors". What am I missing?



[anand]

I purchases a TS508WS off of Amazon and updated it over Wifi when I took it out of the box. I tried reprogramming a new set of MX sensors with the TS508WS. I was not able to get it to work. I could successfully read the IDs for the stock sensors and record them, but I was unable to reprogram the new sensors. It seems like Autel removed the ability to set the IDs of their sensors. What am I missing?

Try updating over a wired connection to a PC; mine refused to properly (fully) update over wifi initially, however, since then updates alright.

Additionally, make sure that the "safety" of programming sensors after being inflated(mounted) is turned off in the settings. I also had much better luck when selecting Europe as the region and then the vehicle



[TheDocAUS]

I purchases a TS508WS off of Amazon and updated it over Wifi when I took it out of the box. I tried reprogramming a new set of MX sensors with the TS508WS. I was not able to get it to work. I could successfully read the IDs for the stock sensors and record them, but I was unable to reprogram the new sensors. It seems like Autel removed the ability to set the IDs of their sensors. What am I missing?

Did you try and change country to Europe in settings? It was the one that originally worked.



[Weatherman]

Did you try and change country to Europe in settings? It was the one that originally worked.

Yes. It doesn't seem to matter whether it is set to Europe to America. In either case the Grenadier is available as a vehicle option, but this is what the Program Sensor menu looks like.



[Weatherman]

Try updating over a wired connection to a PC; mine refused to properly (fully) update over wifi initially, however, since then updates alright.

Additionally, make sure that the "safety" of programming sensors after being inflated(mounted) is turned off in the settings. I also had much better luck when selecting Europe as the region and then the vehicle

Updates worked fine. And that "TPS Prog Limit" is off -- and was by default. still no luck getting a programming option though.



[MTNDOG]

I have an older non-wifi version, last updated back in June 24. Does yours match this or have a new date range?

I have 3 options to program



[Weatherman]

I get the same dates. Further Google suggests Autel has removed the needed functionality to manually program TPMS IDs. And they don't yet support cloning by OBD for the IG. Don't go ordering a new unit and expect it to work.

Warning - Autel MaxiTPMS no longer will clone TPMS sensors (the standalone units, don't know about the pad/computer setup).

Just got off the phone with Autel tech support. My new MaxiTPMS unit is useless for the sensor replacement on my C14. They say their units manufactured after September 2023 will no longer support 'copy by activation', meaning scan old Kawasaki sensor then program that to the new MX Sensor...

forum.concours.org



[DAMON20R]

I can confirm. I just bought a TS508 WF and the only option is the auto create. I bought it to program sensors for my motorcycle, so now I have a $200 paperweight. I will never understand why companies remove features with updates.



[TheDocAUS]

I will never understand why companies remove features with updates.

Because like software, they often put bells and whistles ahead of core functionality.



[parb]

Thanks for the note. I'll make sure to not update mine. I programmed mine without any issues.

have you logged a case with autel yet? This sounds like a defect.



[Weatherman]

Thanks for the note. I'll make sure to not update mine. I programmed mine without any issues.

have you logged a case with autel yet? This sounds like a defect.

I didn't bother based on what I've found elsewhere online. This is a known "feature" of the new units. The advertising is ambiguous at best.



[IslandFalconer]

I didn't bother based on what I've found elsewhere online. This is a known "feature" of the new units. The advertising is ambiguous at best.

That’s interesting purchased mine in September, programmed my new sensors no problem. I had to update it and register it. But it was flawless.
