What did you do with your Grenadier today?

TheDocAUS

Grenadier Owner
Lifetime Supporter
Local time
10:36 PM
Joined
Mar 8, 2023
Messages
2,416
Reaction score
4,225
Location
Eromanga
GRENADIER DRAWERS, WIND AND WATER
I picked up the car this morning. I looked at my car and the other Grenadier being worked on. Very different builds and requirements, but excellent work on both. The other car had a false floor to fit the Lithium auxiliary battery, single drawer, fridge slide, Roo bar lightbar and work lights on the sides and back (Rok 3 work lights by Perception lighting).

The upside of letting my car being used for a photo session are some images I can post here (with permission).

I talked Offroad Systems (ORS) into joining the forum as a supporting vendor. ORS has dealers in most States of Australia. One drawer set and fridge slide was all wrapped up on a pallet about to go off to Western Australia. ORS specialise in custom work. I had ORS drawers and a water tank in the Patrol for 12 years - they are Outback proven and corrugation proof.

I described some of the work done on the car above, but I will let the images do the talking now. The moveable drawer dividers are not shown in the images. Enjoy:


Last edited:

globalgregors

Photo Contest Winner
Grenadier Owner
Lifetime Supporter
Local time
10:36 PM
Joined
May 15, 2022
Messages
1,522
Reaction score
3,956
Location
Sydney NSW, Australia
GRENADIER DRAWERS, WIND AND WATER
I picked up the car this morning. I looked at my car and the other Grenadier being worked on. Very different builds and requirements, but excellent work on both. The other car had a false floor to fit the Lithium auxiliary battery, single drawer, fridge slide, Roo bar lightbar and work lights on the sides and back (Rok 3 work lights by Perception lighting).

The upside of letting my car being used for a photo session are some images I can post here (with permission).

I talked Offroad Systems (ORS) into joining the forum as a supporting vendor. ORS has dealers in most States of Australia. One drawer set and fridge slide was all wrapped up on a pallet about to go off to Western Australia. ORS specialise in custom work. I had ORS drawers and a water tank in the Patrol for 12 years - they are Outback proven and corrugation proof.

I described some of the work done on the car above, but I will let the images do the talking now. The moveable drawer dividers are not shown in the images. Enjoy:

View attachment 7853572View attachment 7853573View attachment 7853574View attachment 7853575View attachment 7853576View attachment 7853577View attachment 7853578
Looking great! What’ve you got where the rear seat would normally be? More storage?


ECrider

Grenadier Owner
Lifetime Supporter
Local time
11:36 AM
Joined
May 4, 2022
Messages
3,353
Reaction score
5,594
Location
UK
GRENADIER DRAWERS, WIND AND WATER
I picked up the car this morning. I looked at my car and the other Grenadier being worked on. Very different builds and requirements, but excellent work on both. The other car had a false floor to fit the Lithium auxiliary battery, single drawer, fridge slide, Roo bar lightbar and work lights on the sides and back (Rok 3 work lights by Perception lighting).

The upside of letting my car being used for a photo session are some images I can post here (with permission).

I talked Offroad Systems (ORS) into joining the forum as a supporting vendor. ORS has dealers in most States of Australia. One drawer set and fridge slide was all wrapped up on a pallet about to go off to Western Australia. ORS specialise in custom work. I had ORS drawers and a water tank in the Patrol for 12 years - they are Outback proven and corrugation proof.

I described some of the work done on the car above, but I will let the images do the talking now. The moveable drawer dividers are not shown in the images. Enjoy:

View attachment 7853572View attachment 7853573View attachment 7853574View attachment 7853575View attachment 7853576View attachment 7853577View attachment 7853578
That looks like fine quality. Also like where you/they've placed the twin compressor.


TheDocAUS

Grenadier Owner
Lifetime Supporter
Local time
10:36 PM
Joined
Mar 8, 2023
Messages
2,416
Reaction score
4,225
Location
Eromanga
Looking great! What’ve you got where the rear seat would normally be? More storage?
Bed extension, seen here. Yes more storage.

The Bed extension is removable to get to the battery box.

The tie down rings on the bed extension you see, were the ones removed to mount the ARB Twin Air Compressor in the rear. ORS sure had some great tricks.

Last edited:

TheDocAUS

Grenadier Owner
Lifetime Supporter
Local time
10:36 PM
Joined
Mar 8, 2023
Messages
2,416
Reaction score
4,225
Location
Eromanga
That looks like fine quality. Also like where you/they've placed the twin compressor.
We worked together on that. Only twins available were ARB Portable twin compressors. So ORS took it out of the case and mounted it there, with a custom mount they made. The mount is secured into the tie down points on the side wall. ORS removed the INEOS tie down rings and bolted in the mount.

I wanted air circulation around the compressor, hence the position. It was a cleaner less cluttered fit on the driver's side than the passenger's side (RHD). You see the power outlets on the passenger's side.

The On/Off switch and hose connector are within easy reach of the rear doors. We did a test before making the mount.

Last edited:

rovie

Grenadier Owner
Lifetime Supporter
Local time
6:36 AM
Joined
May 19, 2022
Messages
2,132
Reaction score
4,003
We worked together on that. Only twins available were ARB Portable twin compressors. So ORS took it out of the case and mounted it there, with a custom mount they made. The mount is secured into the tie down points on the side wall. ORS removed the INEOS tie down rings and bolted in the mount.

I wanted air circulation around the compressor, hence the position. It was a cleaner less cluttered fit on the driver's side than the passenger's side (RHD). You see the power outlets on the passenger's side.

The On/Off switch and hose connector are within easy reach of the rear doors. We did a test before making the mount.
Looks really good. Great work. It's nice to follow this documentary. Thanks.


Krabby

Global Grenadier 76
Forum Moderator
Grenadier Owner
Lifetime Supporter
Local time
6:36 AM
Joined
Nov 5, 2022
Messages
5,078
Reaction score
9,719
Location
New Jersey, USA
I haven’t added these yet (need to think it out and find a few days without rain) but check out these fun stickers I got on Redbubble. I don’t know if the “Achievement Unlocked” is from a video game or something (I don't recognize the symbol nor did two of my nerdiest students, so it might just be made up), but I think it’s perfect for those who have waited so long to get their trucks.


Last edited:

crashnburn

Grenadier Owner
Lifetime Supporter
Local time
5:36 AM
Joined
Feb 19, 2023
Messages
318
Reaction score
503
Location
Illinois
I haven’t added these yet (need to think it out and find a few days without rain) but check out these fun stickers I got on Redbubble. I don’t know if the “Achievement Unlocked” is from a video game or something (I don't recognize the symbol nor did two of my nerdiest students, so it might just be made up), but I think it’s perfect for those who have waited so long to get their trucks.
Maybe this one too.



trobex

Grenadier Owner
Local time
11:36 AM
Joined
Dec 23, 2022
Messages
1,847
Reaction score
2,409
Location
Australia
My day off. Or should I say "off" , for usually it involves much physical labour.
I am adopting @Logsplitter screen name for this afternoon's activity.
Often I go at it with an axe or blocksplitter , but I had accumulated a pile of gnarly hard gum and wattle logs , many with branches.
Impossible to split by hand (I'm a senior after all) so I called in the cavalry. Even my wife had a go. She is also strong on plough.
View attachment 7853009
View attachment 7853010
View attachment 7853011
All we saw here was some 'ripped' old fella!


Logsplitter

Photo Contest Winner
Grenadier Owner
Lifetime Supporter
Local time
11:36 AM
Joined
Oct 31, 2022
Messages
2,824
Reaction score
10,085
Location
🇬🇧
GRENADIER DRAWERS, WIND AND WATER
I picked up the car this morning. I looked at my car and the other Grenadier being worked on. Very different builds and requirements, but excellent work on both. The other car had a false floor to fit the Lithium auxiliary battery, single drawer, fridge slide, Roo bar lightbar and work lights on the sides and back (Rok 3 work lights by Perception lighting).

The upside of letting my car being used for a photo session are some images I can post here (with permission).

I talked Offroad Systems (ORS) into joining the forum as a supporting vendor. ORS has dealers in most States of Australia. One drawer set and fridge slide was all wrapped up on a pallet about to go off to Western Australia. ORS specialise in custom work. I had ORS drawers and a water tank in the Patrol for 12 years - they are Outback proven and corrugation proof.

I described some of the work done on the car above, but I will let the images do the talking now. The moveable drawer dividers are not shown in the images. Enjoy:

View attachment 7853572View attachment 7853573View attachment 7853574View attachment 7853575View attachment 7853576View attachment 7853577View attachment 7853578
Very nice 😍. The first kit out of a two seater utility wagon. That’s given me some ideas for mine. 👍🏼


AngusMacG

Grenadier Owner
Lifetime Supporter
Local time
6:36 AM
Joined
Nov 6, 2023
Messages
746
Reaction score
1,108
Location
Massachusetts, USA
Got back to my hotel last night and as I parked a few college students were checking out the Grenadier. When I got out one of them said “This is the first Grenadier I’ve seen in person!”. I was like you’re the first person that has known what it is! He and his friends checked it out a bit and asked questions. It was very nice not to have to explain the vehicle background. 😀


TheDocAUS

Grenadier Owner
Lifetime Supporter
Local time
10:36 PM
Joined
Mar 8, 2023
Messages
2,416
Reaction score
4,225
Location
Eromanga
Very nice 😍. The first kit out of a two seater utility wagon. That’s given me some ideas for mine. 👍🏼
Logsplitter
A couple of extra points that may help.
  1. Aluminum drawers, not steel to save on weight;
  2. Double runners on drawers, as insurance against damage by corrugations (I know it works as my Patrol had the same for 12 years and it survived many, many corrugations);
  3. Removable bed extension, so I can access the battery box. Brackets on the cargo barrier for the bed extension, do not impede opening the battery box lid;
  4. Double drawers rather than a drawer/fridge slide combination, as I mount my fridge on the front passenger seat – not an option for most people;
  5. After seeing @globalgregors build, I went for the deeper drawers, but the main reason was to give me more storage under the bed extension, an added benefit was more drawer space. Very happy with the results;
  6. I may yet cut out part of the cargo barrier to allow me access to the rear between the two front seats;
  7. Drawer dividers not shown in the images, but they are important to have if the drawers are not full, to avoid things sliding all over the place. They just fit in where you place them;
  8. The vertical space to the battery box lid, is less than the vertical space to the seats in a 5 seater model;
  9. The stainless-steel water tank sits above and just behind the battery box. The tank sits in its own tray, that tray has drainage hoses to either side of the battery box, so any water leak does not spill onto the electrics in the battery box;
  10. I and my sparky/installer did a lot of electrical work before the fitout, as the trim is now hard to remove in the rear (Dashcam, Anti Rust system wiring, Anderson plugs x 4 (including two solar plugs), Redarc TowPro, etc.);
  11. The water nozzle is gravity feed and accessible from the passenger door (RHD), but you can have a 12 volt version to some other location; and
  12. I am pleased with the position of the twin air compressor. It was going to be wired to the spare stud on the 7-stud busbar, but the cable did not reach (the wiring cable length on the portable air compressor was already preset by ARB). We went to plan B, the spare stud on the 5-stud busbar as it was closer to the compressor. I pointed out both options to ORS before we started (thank you INEOS for giving us this option). The twin compressor has two 40-amp circuits, so the wire ends in the battery box was not an option. Although they are fine for a single ARB compressor. I bought an 80 amp ZCase MEGA fuse to use on the spare stud. The spare stud on the 7-stud busbar has a bolt, the spare on the 5-stud busbar does not (I sourced a bolt).
Ask if I can help with anything else, you have done so much to help us on the forum.

Last edited:

Logsplitter

Photo Contest Winner
Grenadier Owner
Lifetime Supporter
Local time
11:36 AM
Joined
Oct 31, 2022
Messages
2,824
Reaction score
10,085
Location
🇬🇧
Logsplitter

A couple of extra points that may help.
  1. Aluminum drawers, not steel to save on weight;
  2. Double runners on drawers, as insurance against damage by corrugations (I know it works as my Patrol had the same for 12 years and it survived many, many corrugations);
  3. Removable bed extension, so I can access the battery box. Brackets on the cargo barrier for the bed extension, do not impede opening the battery box lid;
  4. Double drawers rather than a drawer/fridge slide combination, as I mount my fridge on the front passenger seat – not an option for most people;
  5. After seeing @globalgregors build I went for the deeper drawers, but the main reason was to give me more storage under the bed extension, an added benefit was more drawer space. Very happy with the results;
  6. I may yet cut out part of the cargo barrier to allow me access to the rear between the two front seats;
  7. Drawer dividers not shown in the images, but they are important to have if the drawers are not full, to avoid things sliding all over the place. They just fit in where you place them;
  8. I did a lot of electrical work before the fitout, as the trim is now hard to remove in the rear (Dashcam, Anti Rust system wiring, Anderson plugs x 4 (including two solar plugs), Redarc TowPro, etc.); and
  9. I am pleased with the position of the twin air compressor. It was going to be wired to the spare stud on the 7-stud busbar, but the cable did not reach (the wiring cable length on the portable air compressor was already preset by ARB). We went to plan B, the spare stud on the 5-stud busbar as it was closer to the compressor. I pointed out both options to ORS before we started (thank you INEOS for giving us this option). The twin compressor has two 40-amp circuits, so the wire ends in the battery box was not an option. Although they are fine for a single ARB compressor.
Ask if I can help with anything else, you have done so much to help us on the forum.
Thankyou so much.
Can’t wait to get our Grenadier back so we can start kitting it out. After living with it in its stock form for six months travelling we have some ideas. If there is an option in the U.K. for an approved auxillary fuel tank then this may influence our decision as to what we do, if we didn’t need to take extra fuel on the roof rack then we may possibly go with a lifting roof conversion such as Alucab. No rush just watching what comes up and what is available for a while.


bbq4133

Grenadier Owner
Lifetime Supporter
Local time
6:36 AM
Joined
Feb 20, 2024
Messages
198
Reaction score
303
Location
Delaware, USA
Got back to my hotel last night and as I parked a few college students were checking out the Grenadier. When I got out one of them said “This is the first Grenadier I’ve seen in person!”. I was like you’re the first person that has known what it is! He and his friends checked it out a bit and asked questions. It was very nice not to have to explain the vehicle background. 😀

That was me with pretty much everyone last weekend on the trails in Virginia. Very cool lol


crashnburn

Grenadier Owner
Lifetime Supporter
Local time
5:36 AM
Joined
Feb 19, 2023
Messages
318
Reaction score
503
Location
Illinois
Installed the Wolfbox 900.
Everything was easy except the part where you need to feed the line vertically at the rear cargo area and going to the rear door.
Ended up not routing through the rubber tube as it was too tight and didn't want to damage any wires. Routed the wire outside with some wrap. Just need to do some cleanup with the wires.

Tested and it is really nice seeing what is behind the Grenadier!

By the way, I got the screen protector and it gives the rear view mirror a slight blur so I may have to take it off.
